Single Axis Actuator
>
|
| Place of Origin | China |
| Brand Name | ZANE |
| Certification | CE,ISO |
| Model Number | F190P |
Single Axis Actuator
This mechanical motion device is designed to provide a rotational motion unit for a wide range of applications including automation equipment, photovoltaic industry, and laser equipment. The Single Axis Actuator (Model Number: F190P) is capable of achieving a stroke length of 100mm and a speed of 1000mm/s. It is designed for precision and longevity, ensuring reliable performance in any application. It is an ideal choice for users looking for a reliable and efficient rotational motion unit.
| Driver power(W) | 750W | |||
| Ball screw (16) mm lead | P05:5 | P10:10 | P20:20 | |
| Maximum speed(mm/s): | 250 | 500 | 1000 | |
| Maximum handling weight(kg) | Level | 120kg | 100kg | 50kg |
| Perpendicularity | 60kg | 50kg | 30kg | |
| Repeated positioning accuracy (mm): | Class C +0.02mm; P level +0.01mm | |||
| Range of travel(mm): | The range is 50 to 500mm | |||
| Load moment(N.m ) | Mx:110; My:150; Mz:120 | |||
| Load mechanism | GEH20 Dual track | |||
| Driving mechanism | Grade C. 16 to grade C7; Grade P ·16 Grinding grade C5 | |||
| Base material | Hard extruded aluminum profile, luster itself | |||
| Installation surface accuracy requirements | Less than 0.05mm | |||
| Dust proof design | Full seal dust proof | |||
| Stroke(S) | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 |
| L1 | 35 | 40 | 45 | 50 | 55 | 60 | 65 | 70 | 75 |
| L2 | 295 | 350 | 415 | 470 | 525 | 580 | 635 | 690 | 745 |
| L3 | 330 | 390 | 480 | 520 | 580 | 640 | 700 | 760 | 820 |
| L | 438 | 498 | 568 | 628 | 688 | 748 | 808 | 868 | 928 |
Q: What's your main products?
A: ball screws, ball screw support units, Linear guide rails,Linear Guide Module,Rack and Pinion,Nidec Shimpo Gearbox
Q: When can I get the quotation?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price,please call us or tell us in your email so that we will regard your inquiry priority.
Q: Can you do ball screw end machine processing?
A: Yes. We have a professional team having rich experience in end machine processing,Please provide us the drawing with the tolerance, we will help you to make the ball screws depending on the drawing.
Q: How can I get a sample to check your quality?
A: After price confirmation, sample order is available to check our quality.
Q: Have items 100% finished in stock?
A: Most items are all well finished in stock, but some items are newly machined according to your requirements.
Q: Can I choose the sizes?
A: Yes, We have full size available for your to choose.
